Hexagonal Gabion

Hexagonal Gabion Box is made of hot dipped galvanized steel wire /heavy galvanized coating steel wire/ PVC coated wires, the mesh shape is hexagonal style.The gabion retaining wall are used widely in slope protection,mountain rock holding,gabion for river bank protection

Kirim email ke kami Unduh sebagai PDF

Rincian produk

Label Produk

Hexagonal Gabion Box is made of hot dipped galvanized steel wire /heavy galvanized coating steel wire/ PVC coated wires,

the mesh shape is hexagonal style.The gabion retaining wall are used widely in slope protection,mountain rock holding,

gabion for river bank protection.

Bukaan (mm)	Diameter Kawat (mm)	Edge wire (mm)	Gabion Sizes (M)	Bahan (zinc coating)
60x80mm	2.2mm/2.7mm	2.4mm/3.4mm	6x2x0.3m/2x1x0.5m	1.galvanized steel wire 2.high zinc steel wire 3.pvc coating steel wire
80x100mm	2.7mm/3.0mm/3.2mm	2.4mm/3.4mm	2x1x1/3x1x1m/4x1x1m
100x120mm	3.0mm/3.05mm/3.2mm	3.4mm	3x1x1/4x1x1m/5x1x1m

Gabion Baskets can be made Gabion retaining wall, Desert gabion, Gabion Channel linings, Rockfall protection, Gabion landscaping, drainage, Gabion bank, Roadway and bridge protection, Erosion protection, Slope pavingand weirs, Earth reinforcing structures, Hydraulic structures, Outfall structures, Coastal embankment works, Dams and culverts.
