Maikling Paglalarawan
Materyal: Mababang carbon na bakal, High Tensile Steel, Galvanized Wire
Pag-uuri:
I.Electric galvanized
II.Hot dipped galvanized
III. High hot dipped galvanized
Packaging: sa roll, bawat roll ay may habi bag sa dalawang ulo
-
Hinge Knot Joint Fence
-
Fixed Knot Field Fence
-
Square Deal Knot Fence
Common hinged joint fencing is made from galvanized wire with a wire diameter of 2.5 mm and the top and bottom wire are made with wire diameter of 2.8 mm. Fence height is normally from 0.8m to 2m. A variety of heights, hole mesh, spacing and styles are offered for more choices.
Fixed knot field fence is reinforced at each wire intersection both horizontally and vertically. There's no risk of the horizontal wires sliding if animals try to climb the fence.Fixed knot deer fence is the strongest fence type with increased post spacing, highest visibility and low maintenance-which takes advantage of fixed knots formed by using separate wires to tie the continuous horizontal and vertical wires together without sliding.
Square Deal Knot Field Fence(S Knots Fence) has s-shaped knots to form a tough & sturdy structure that stands up to impact from large animals without buckling or sagging. It is a type of anti climbing fence, suitable for goat, sheep and cattle keeping. It is not welded style, is woven type could keeping longer life.
|
BAkod ng baka
|
|
Mga sukat ng mesh
|
GW(KG)
|
Wire diameter(mm)
|
|
7/150/813/50
|
102+114+127+140+152+178
|
19.3
|
2.0/2.5mm
|
|
8/150/813/50
|
89(75)+89+102+114+127+140+152
|
20.8
|
2.0/2.5mm
|
|
8/150/902/50
|
89+102+114+127+140+152+178
|
21.6
|
2.0/2.5mm
|
|
8/150/1016/50
|
102+114+127+140+152+178+203
|
22.6
|
2.0/2.5mm
|
|
8/150/1143/50
|
114+127+140+152+178+203+229
|
23.6
|
2.0/2.5mm
|
|
9/150/991/50
|
89(75)+89+102+114+127+140+152+178
|
23.9
|
2.0/2.5mm
|
|
7/150/1245/50
|
102+114+127+140+152+0178+203+229
|
26.0
|
2.0/2.5mm
|
|
10/150/1194/50
|
89(75)+89+102+114+127+140+152+178+203
|
27.3
|
2.0/2.5mm
|
|
10/150/1334/50
|
89+102+114+127+140+152+178+203+229
|
28.4
|
2.0/2.5mm
|
|
11/150/1422/50
|
89(75)+89+102+114+127+140+152+178+203+229
|
30.8
|
2.0/2.5mm
|
|
DEER NET
|
|
Vertical wire na distansya
|
3'',4'',5'',6'',7''
|
|
Lapad ng mesh
|
75mm, 150mm, 300mm, 450mm(3'' ,6'', 12'', 18'')
|
|
Wire diameter
|
2.4mm-2.6mm
|
|
Knot wire
|
2.0mm-2.24mm
|
|
Lapad ng roll
|
Anumang haba ≤2.5m
|
|
Haba ng roll
|
50m, 100m ,200m
|
Farm fencing ay ang pinakamahusay na pagpipilian ng mga rancher para sa pagprotekta sa mga tumatalon na hayop tulad ng mga usa, kabayo at baka, tupa at kambing. Tinitiyak ng hinge-knot system ang tamang pag-uunat at nagbibigay-daan para sa mas madaling pag-install sa maburol o mabangis na lupain. Ang paggamit ng aming hinge-joint knots ay nagbibigay-daan sa bakod na magbigay sa ilalim ng presyon at bumalik sa hugis. Ang mabigat na zinc coating ng wire ay nag-aalok ng tapos na fencing na mahusay na lumalaban sa kalawang at kaagnasan.
Nakapirming buhol na bakod ng usa Madaling gawin ang pag-install. Tamang-tama para sa lahat ng mga lupain, pati na rin ang mga kural at pastulan, na makatiis sa mga hinihingi ng pagsasama-sama ng malalaking kawan ng hayop, ang galvanized wire ay lumalaban sa pagbabago ng panahon pati na rin ang pagkasira.
